1) eccentric short roller bearing
偏心短圆柱轴承
1.
The structure of an eccentric short roller bearing is denoted, methods are given for determining the bearing clearance, its eccentricity and its lift estimate, by which a double row eccentric short roller bearing is designed and manufactured.
介绍了偏心短圆柱轴承的结构 ,给出了确定偏心短圆柱轴承间隙、轴承偏心距及轴承寿命估算的方法。
2) Hollow Cylindrical Roller Bearing
空心短圆柱滚子轴承
1.
Application of Hollow Cylindrical Roller Bearing in Precision Grinding Machine;
空心短圆柱滚子轴承在精密磨床上的应用
4) cylindrical roller bearing
(短)圆柱滚子轴承
6) double row cylindrical roller bearing
双列短圆柱滚子轴承
1.
Dynamic characteristics analysis for double row cylindrical roller bearing with taper hole;
锥孔双列短圆柱滚子轴承的动态特性分析
2.
Improvement of inner ring rib grinding technology for double row cylindrical roller bearings;
双列短圆柱滚子轴承内圈挡边磨工艺改进
3.
In this paper, the dynamic characteristic of the double row cylindrical roller bearing with taper hole has been analyzed.
本课题结合江苏省十五科技攻关项目(BE2004025)和江苏省的自然科学基金项目(BK2002059),对磨床用高速电主轴轴承进行了系统地油气润滑试验研究,旨在为电主轴摩擦学设计提供重要参数,同时分析了锥孔双列短圆柱滚子轴承的动态特性。
补充资料：在AutoCAD中偏心圆锥与偏心圆台实体的画法
现在要画一个偏心圆锥,底面在WCS的XY平面上,圆心(0,0,0),半径100,顶点(300,0,400)在ZX平面上.
1)连接PA,PB. A(-100,0,0) B(100,0,0)
图1
在当前坐标下:
2)延长PA到C,使PA=CA;延长PB到D,使PB=DB;
3)连接CD;
4)以CD为直径画圆;
5)用XLINE命令中的二等分选项作角CPD的角平分线PO,交CD于O;
6)过O作CD的垂线,交圆于E,F;
图2
7)用三点UCS命令,取三点为:O,P,C;
8)过点O作PO的垂线GO,交PC于G;
图3
9)再次用三点UCS命令,取三点为O,F,G;
10)现在就可以画椭圆锥了!
cone-e-c-捕捉O点-捕捉F点-捕捉G点-a-捕捉P点;
图4
11)回到WCS,剖切椭圆锥
SL-选择椭圆锥-回车-XY-回车-捕捉P点.
12)删除辅助线条.
图5
